Single Cylinder Double Doffer Nonwoven Carding Machine
Use
This machine include single cylinder、double doffer、four disorder roller and web stripping . All rollers of the machine are subject to conditioning and qualitative treatment before precision processing. The wallboard is made of cast iron. Use high-qulity card wire.It has the advantages of strong carding ability and high output
The working width of our non woven carding machine can be customized from 0.3M to 3.6M, and the output of a single machine is from 5kg to 1000kg.Our non woven carding machine can provide auto-leveller to make the produced cotton web more uniform and ensure the quality of the product;
The roller diameter of our non-woven carding machine can be customized to meet different types and lengths of fibers, suitable for a wide range of spinning and applications.
Specification
| (1)Work width | 1550/1850/2000/2300/2500mm |
| (2)Capacity | 100-500kg/h,depend on fiber type |
| (3)Cylinder diameter | Φ1230mm |
| (4)Doffer diameter | Φ495mm |
| (5)Feeding roller diameter | Φ86 |
| (6)Work roller diameter | Φ165mm |
| (7)Stripping roller diameter | Φ86mm |
| (8)Linker-in diameter | Φ295mm |
| (9)Diameter of stripping roller used for web output | Φ219mm |
| (10)Disorder roller diameter | Φ295mm |
| (11)Installed power | 20.7-32.7KW |
Features
(1) The frames on both sides are welded by high-quality steel plates, and the middle is supported by strong steel, structure is stable.
(2) The feeding roller is equipped with metal detector and self stop reverse device to ensure the safe operation of the carding machine.
(3) There are working platforms on both sides of the carding machine, which is more convenient for use and maintenance.
