Nonwoven High Grade Bale Opener with Automatic Weighting
Use
Pre open the baled fibers with various grades and feed them in a set up amount. When multiple machines are used together, different fibers can be mixed in proportion. The proportion can be automatically controlled according to the settings, so that different fibers can be accurately proportioned and evenly mixed.
Features
The automatic weighing bale opener has a high reputation in the industry. The automatic weighing bale opener has a wide range of applications and can adapt to various non-woven production lines, spinning production lines, etc.
Several automatic weighing bale opener form a unit, which can accurately batch and mix various raw materials according to the specified ratio, and produce various products that meet customer needs.
This machine adopts four weighing sensors for precise weighing, through PLC calculation, feeding, retrieving and dropping, etc., adopts frequency conversion adjustment to control the weight of corresponding fibers, and accurately weighs and mixes various raw materials.
Working principle
The output position of each bale opener is installed electronic weighing system, and the feeding of weighing hopper is controlled by frequency converter, so that each weighing machine is accurate;
When multiple bale openers are working, set according to the ratio. After each bale opener obtains the corresponding weight of raw materials according to the instructions, the fibers shall be simultaneously dropped onto the conveying belt which is used for next process.
Specification
| （1）Work width： | 1200mm、1300mm、1400mm、1500mm、1600mm |
| （2）Capacity | ≤250kg/h 、 ≤350kg/h 、 ≤350kg/h 、≤400kg/h 、 ≤500kg/h |
| （3）Power | 3.75kw |
Mechanism characteristics
(1) The frame is welded by high-quality steel plates, and the structure is stable.
(2) The use of new electronic weighing structure saves labor.
(3) All transmission parts are protected by protective covers.
(4) The electrical part is installed with overload protection, overcurrent protection, short circuit protection and emergency stop button.
(5) Warning signs shall be set at necessary positions.
